Every change is a version.
“Make the nose stick out 25 mm.” Version 2 lands next to version 1, outlined in orange. Go back any time: the chat and what the agent remembers come back too.
CAD Studio
Describe a part. Print it.
Parametric CAD, written and run by the coding agent on your Mac.
This push-to-open latch was made in CAD Studio from one prompt.
You type
A fully 3D-printed push-to-open latch for a drawer, about 80 mm long. A heart-shaped cam, a printed spring, four colors. Animate a full cycle.
9 minutes later, it clicks. Simulated, collision-checked, ready to print.
Watch it take shape.
Then hold the result.
Every step streams into the chat as it happens: the code being written, the model being built, the drawing being checked. The 3D view, the parameters and the technical drawing land the moment the files do.
A fully 3D-printed push-to-open latch for a drawer, about 80 mm long: a housing with a lid, a plunger with a heart-shaped cam groove, a follower pin and a printed serpentine spring. Give it four colors so each part stands out. Animate a full cycle: push to latch, push again and the spring pushes it back out.
Writing the model · 843 lines
Checking the drawing
Drawings are almost done; one callout still overlaps an edge, so I'm moving it.
Editing the model
I've built the latch. It's an 80 × 30 mm housing with screw flanges and a lid, a plunger with a heart-shaped cam groove that sticks out 18.5 mm, a sliding follower pin, and an 8-beam printed serpentine spring.
Simulated cycle: the first push goes in 15 mm and the plunger holds at 12 mm. The second push releases it and the spring returns it fully, with no collisions. Spring force runs from about 2.4 N at rest to about 11.3 N fully pushed.
One latch.
Five parts.
Laid flat, ready to print.
Assembled, exploded or laid out on your print bed. Hide a part, keep two together, open the plate in your slicer.
See it click
before you print it.
Ask for an animation and the agent simulates the mechanism: the spring, the cam and the push of your finger. The real solids are checked for collisions in every frame.
Rest
- Plunger travel
- 0.0mm
- Spring force
- 2.4N
- Finger force
- 0.0N
- Collisions
- 0of 189 frames
Drawings, sheet by sheet.
An ISO first-angle drawing comes with every model. The latch got six: the assembly with its parts list, then one sheet per part, all in a single PDF.
Measure it.
Cut it open.
Click two points for the distance and its X, Y and Z deltas. Slide a section plane along any axis to see inside, down to the cam groove and the spring.
Everything a maker needs.
Nothing in the way.
Ready for the bed.
Every part laid flat in its print orientation, with 0.2 mm of play between the sliding parts.
The numbers that matter.
Straight from the latch's parameters and simulation.
- Stroke
- 15 mm
- Latched depth
- 12 mm
- Nose out
- 18.5 mm
- Spring
- 8 beams
- Spring force
- 2.4–11.3 N
- Sliding fit
- 0.2 mm
Every file you need.
One click exports the lot as a ZIP.
Yours, on your Mac.
CAD Studio runs the agent you already use, in a folder you choose. No accounts, no servers, nothing uploaded by the app.
Show it what you mean.
Paste a screenshot with ⌘V, or drop in a sketch, a photo, a PDF drawing or the STEP of the part it has to fit. The agent measures what it can instead of guessing.
Line up the next idea.
Keep typing while it works. Messages wait in a queue and go out one by one as each version finishes. If something fails, the queue pauses for you.
Everything in the box.
One app, from the first sentence to the file on your print bed.
Design
- Chat that writes and fixes the parametric model for you
- Named parameters as sliders, rebuilt locally in seconds
- Reference images, sketches, PDFs and STEP or STL files
- Message queue that sends the next request when a version is done
- Build checks on every run: valid solids, warnings and errors in the chat
View
- Live 3D view with orbit, zoom, pan, grid and wireframe
- Multi-color 3MF parts, shown in their real colors
- Assembled, exploded and print plate views
- Show, hide or keep parts together
- Point-to-point measurements and section planes on X, Y and Z
Simulate
- Mechanisms animated by a physics simulation
- Masses, springs, friction and the force of your hand
- Collision checks on the real solids while it moves
- Live readouts of speeds, angles and forces as it plays
Document
- ISO first-angle technical drawings with every model
- Assembly sheet with balloons and a parts list
- One sheet per part, with its own dimensions
- All sheets in one multi-page PDF
- Design rules for FDM, multi-material, resin and SLS
- Print plate with every part oriented and laid out
- The print plate opened straight in your slicer
- STEP, 3MF, STL, the PDF drawing and the source script in one ZIP
Work your way
- Every generation saved as a version, chat and context included
- Compare any two versions in 3D
- Panels you can drag anywhere, layout saved per project
- Each project is a plain folder you can open, copy or back up
- English, Italian, German and French
Bring your own agent.
CAD Studio has no AI of its own and no account to make. It drives the coding agent already signed in on your Mac, with your plan, and you can switch agents in Settings at any time.
-
You describe it.
In words, with pictures or with the file it has to fit. In millimeters or inches.
-
The agent writes the code.
A parametric script with every dimension as a named parameter, plus the drawing and the simulation.
-
It runs and checks.
The model is built right on your Mac. The agent looks at the drawings it produced and fixes what is wrong.
-
You get files.
Ready for your slicer, your CAD app and your workshop, in a folder you own. Nothing leaves your Mac through the app.
Works with
- Claude CodeAnthropic's command line agent
- CodexOpenAI's command line agent
Choose the model and the reasoning effort in Settings.
-
Sign in to your agent.
Install Claude Code and run
claudeonce, or install Codex and runcodex login. CAD Studio uses your plan. -
Open CAD Studio.
Drag it into Applications. It isn't notarized yet, so allow it in Privacy & Security, or run:
xattr -dr com.apple.quarantine "/Applications/CAD Studio.app" -
Describe a part.
Pick your printer and units, and say what you need. Everything else is set up for you on first launch.
